NPS200-2

详细介绍
Specifications

Nominal Votage

2V

Rated Capacity (10 hour rate)

200Ah

Capacity
25℃(77°F)

10 hour rate (20A)

200Ah

3 hour rate (50A)

150Ah

1 hour rate (110A)

110Ah

Internal Resistance

Full charged Battery 25℃(77°F)

0.65 mΩ

Cycle life

50%(C10)          Depth of discharge

800 times

Float life

25℃(77°F)         Float Voltage 13.8V

Approx.
13 years

Capacity affected by Temperature
(10 hour rate )

40℃ (104°F)

102%

25℃ (77°F)

100%

0℃ (32°F)

85%

-15℃ (5°F)

65%

Self-Discharge
25℃(77°F)

Capacity after 3 month storage

90%

Capacity after 6 month storage

80%

Capacity after12month storage

62%

Charging Method
25℃(77°F)

Cycle

Initial Charging Current 50A or small
Constant Voltage 2.43-25.0V

Float

Constant Voltage 2.25-2.30V


Packing Dimension

Product
Dimension

mm±1

173×111×366

Inch

6.82×4.37×14.4

package
Dimension

mm±2

200×250×438

Inch

7.88×9.85×17.3

Package Number / Carton

2

Net Weight / Product

15.5KG±100G

Net Weight / Carton

31KG

Gross Weight / Carton

31.4KG


Discharge Curves











Material

component

Positive Plate

Negative Plate

Container

Safety Valve

Terminal

Separator

Gel

Electrolyte

Material

Lead Doxide

Lead

ABS

Rubber

Lead Terminal

Fiberglass

Silicon Dioxide

Sulphuric Acid


Discharge Characteristic

Voltage

Runtime (Constant Power-Discharge Charateristic 25℃ 77°F )

1H

2 H

3 H

5 H

8 H

10H

1.60V

250

150

109

72.7

47.3

40.7

1.70V

242

146

108

71.3

44.7

40.7

1.75V

238

142

106

69.3

44.7

38.7

1.80V

230

138

103

68.7

44.0

38.0
